Name: Shipping & Barcode Label Printer Brother QL1100 USB
Brand: Brother
SKU: 148357
Price: 343.88 NZD
Availability: InStock

Print from PC and Mac

The free P-touch Editor label design software for PC and Mac lets you add text, images, barcodes and frames to your labels. Link to data contained in an Excel spreadsheet or .csv file, then merge the data onto your label layout to quickly print many labels at once.

Support for Microsoft Office

The P-touch editor add-in for Microsoft Office (Windows only) allows you to select and print data directly from Word, Excel and Outlook. From Microsoft Word, highlight an address and click the add-in, in the toolbar, to print this on a label. Highlight cells in Excel and again click the add-in. For Outlook, select the contact with the address you require to print this label.

General

Database upload from PC	Yes
Housing colour	Glossy black and white
Image upload from PC	Yes
Memory capacity	6 MB
Memory locations	99
Technology	Direct thermal
Template upload from PC	Yes

General Supplies

Type	DK rolls (DK die-cut labels / DK continuous length tape)

Connectivity

USB interface	Ver 2.0 (full speed)

Dimensions & weights

Dimensions	170mm (W) x 222mm (D) x 151mm (H)
Weight	1.71 kg

In the box

Power supply cord	Yes
Supplies	103mm x 164mm large shipping labels (41 labels) - 62mm continuous length paper tape (8.1 metres)
USB cable	Yes
User guide	Yes
Warranty card	Yes
Quick setup guide	Yes

Network

Wireless network security	WEP, WPA-PSK/WPA2-PSK (TKIP/AES), LEAP (CKIP), EAP-FAST (TKIP/AES), PEAP (TKIP/AES), EAP-TTLS (TKIP/AES), EAP-TLS (TKIP/AES)

Printing

1 dimensional barcode symbologies	CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1 DataBar Stacked,GS1 DataBar Stacked Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,GS1 DataBar Expanded Stacked)
2 dimensional barcode symbologies	PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode, CODE93, POSTNET, UPC-E EXTENTION, MSI, Aztec
Bitmap fonts	Helsinki, Brussels, Letter Gothic Bold, San Diego, Brougham
Maximum label width	103.6 mm
Maximum print length	3000 mm
Maximum print width	101.6 mm
Outline/Vector fonts	Helsinki, Brussels, Letter Gothic
Resolution (dpi)	300 x 300
Standard print speed	110 mm per second

P-touch Editor label design software

Database file compatibility	csv, Microsoft Access, Microsoft Excel
Date and time stamp	Date and time
Fonts	All installed truetype fonts
Frames	126
Label orientations	Horizontal, Vertical
Microsoft Office add-in (highlight->click->print)	Excel, Outlook, Word
Screen capture	Yes
Sequential numbering	1 - 9999 / A - Z / a - z
Text alignment	Centre, Justify, Left, Right
Typestyles	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Vertical print	Yes

Solutions

SDK (Software Development Kit)	Yes
